Icynene Corp.
spray foam insulation

CONTACT INFO

6747 Campobello Rd.
Mississauga, ON, Canada L5N 2L7
Toll Free: 800-758-7325
Phone: 905-363-4040
Fax: 905-363-0102

Icynene Corp. Inc.
438 Main St.
Suite 100
Buffalo, NY 14202-3207
Continuing Education Logo

WARRANTY

For Warranty Information Click Here

COMPANY OVERVIEW

Established in 1986, Icynene Inc. offers a complete portfolio of high-performance spray foam insulation solutions. In the past 30 years, more than 3 billion board feet of Icynene spray foam insulation has been installed in more than 425,000 residential and commercial projects.

ALL PRODUCTS

{{this.show}} {{this.hide}} Spray Foam Insulation Products for Architects

Icynene ProSeal (MC-C-200v3) Closed Cell Spray Foam Insulation image

Icynene ProSeal (MC-C-200v3) Closed Cell Spray Foam Insulation

Ideal for use in exterior continuous insulation applications, ProSeal is a high-performance closed-cell spray foam insulation product that sets a new benchmark in excellence. Icynene ProSeal will allow you to meet today's building code requirements with confidence.

Performance Benefits
  • Core Density: 2.4 lb/ft3
  • R-Value: R-7 per 1"
  • Approved for Type I-V Construction
  • One formulation suitable for year round use
  • Higher initial pass of 3" to achieve R21 in one pass
  • Can be sprayed year round - even at cold temperatures as low as 23o F (-5o C)
  • Low VOC allowing for re-entry after 1 hour, and re-occupancy after 2 hours, of active ventilation
  • Icynene ProSeal has achieved GREENGUARD and GREENGUARD GOLD Certification
Icynene ProSeal Eco (MD-R-210) Closed Cell Spray Foam Insulation image

Icynene ProSeal Eco (MD-R-210) Closed Cell Spray Foam Insulation

Icynene ProSeal Eco is the first 100% water-blown closed-cell spray foam insulation product certified for use in buildings in North America. With no synthetic blowing agent, Icynene ProSeal Eco is a smarter replacement for chemically based medium-density, closed-cell spray foams. Ideal for exterior continuous insulation applications, Icynene ProSeal Eco provides a high-performance all-in-one exterior continuous insulation and air barrier solution for the outer surface of sheathing on a framed wall. Plus, it also smoothly and completely covers all areas that could otherwise permit energy-draining thermal bridges.

Performance Benefits
  • Core Density: 2.2 lb/ft3
  • R-Value: R-4.9 per 1"
  • Approved for Type I-V Construction
  • No ozone-depleting blowing agent, 100% water blown
  • Can be sprayed at temperatures as low as 5F
  • Class II VDR at 1.5" thickness (ASTM E-96)
  • Suitable for both cavity fill and continuous exterior applications
  • Tested in NFPA 285 approved wall assemblies for more design flexibility
  • Wide range of cost effective ASTM E119 tests of rated assemblies for ultimate flexibility
  • One formulation with superior adhesion to common building substrates
Icynene MD-C-200 Closed Cell Spray Foam Insulation image

Icynene MD-C-200 Closed Cell Spray Foam Insulation

Icynene MD-C-200 closed-cell spray foam insulation allows architectural firms to push the limits of design while being able to meet or exceed local building code requirements. A robust, two-pound closed-cell spray foam insulation, Icynene MD-C-200 is a one-step performance material ideal for continuous insulation applications and is ABAA approved.

Performance Benefits
  • Aged Thermal Resistance: 6.6 per inch *
  • Construction Types: I - V
  • Core Density: 2.4lb.
  • Evaluated and listed by ABAA as an air barrier material
  • Class II vapor retarder at 1.5" thickness
  • Meets FEMA criteria for resisting water absorption
  • Compliant to California Department of Public Health EHLB v1.1-2010 Emissions Specification Section 01350
Icynene Classic (LD-C-50) Open Cell Spray Foam Insulation image

Icynene Classic (LD-C-50) Open Cell Spray Foam Insulation

Icynene Classic is a high-performance open-cell spray foam insulation product ideal for use in commercial interior applications. Icynene Classic allows building occupants to experience superior thermal comfort and improved indoor air quality while helping to reduce the risk of moisture problems.

Performance Benefits
  • Aged Thermal Resistance: 3.7 per inch*
  • Construction Types: I - V
  • Core Density: 0.5lb.
  • Superior cold temperature adhesion to multiple substrates
  • <5% water absorption
  • Vapor permeable, support bi-directional drying of assemblies
  • Soft, flexible composition maintains an air seal even after seasonal expansion/contraction of building assembly
Icynene Classic Plus Open Cell Spray Foam Insulation image

Icynene Classic Plus Open Cell Spray Foam Insulation

Icynene Classic Plus is high R-Value open cell spray foam that achieves R-22 in 2x6 wall assemblies. Suited for use in commercial interior applications, the superior performance of Icynene Classic Plus is ideal for architects and builders in areas requiring a higher R-value to meet the latest building codes.

Performance Benefits
  • Aged Thermal Resistance: 4 per inch
  • Construction Types: V B
  • Core Density: 0.7lb.
  • Superior sound control
  • Vapor permeable, support bi-directional drying of assemblies
  • Soft, flexible composition maintains an air seal even after seasonal expansion/contraction of building assembly
Applications-Commercial image

Applications-Commercial

For all these commercial applications, find detail drawings, design notes, 3-part specs, project examples, and more by selecting different parts of the building.

External Wall
Internal Wall
Other Uses

Icynene® spray foam insulation can be applied to any common substrate, such as masonry, concrete, drywall, wood, steel, and more.
Commercial - Sustainability image

Commercial - Sustainability

Bringing sustainable design & spray foam insulation together.

What makes sustainable design and spray foam insulation an ideal combination for architects?
  • On average, 30% of the energy used in commercial buildings is wasted1.
  • Commercial buildings cost their owners more than $100 billion annually in energy costs1.
  • Commercial buildings account for 18% of the nation's energy use and nearly 18% of greenhouse gas emissions1.
  • By 2035, 75% of all buildings will be either new or renovated1.


These facts empower architects to shape a more sustainable future. Energy efficiency is one of the ways Icynene spray foam insulation can contribute to sustainable design. When considering sustainable design and spray foam insulation, most insulation types only deliver R value, but building science teaches us that the inclusion of an air seal like that provided by Icynene spray foam insulation is vital for total building performance.
LEED Contributions of Icynene Insulation Foam Spray image

LEED Contributions of Icynene Insulation Foam Spray

Icynene insulation foam spray products qualify for LEED credits in the categories of Energy & Atmosphere, Innovation & Design, Materials & Resources and Indoor Environmental Quality.

NAHB Approvals of Icynene Insulation Foam Spray.

All Icynene products are green approved products according to the National Green Building Standard of the National Association of Home Builders.
Air Barrier Systems image

Air Barrier Systems

The Air Barrier Association of America (ABAA) defines an air barrier system as a system of building assemblies within the building enclosure designed, installed and integrated in such a manner as to stop the uncontrolled flow of air into and out of the building enclosure. ABAA-evaluated Icynene spray foam insulation products include Icynene ProSeal and MD-C-200.

Use of ABAA-evaluated building materials such as spray foam insulation in your commercial design can contribute to:
  • Reducing building enclosure moisture problems
  • Improving indoor air quality
  • Reducing building heating and cooling costs
  • Reducing greenhouse gas production

{{this.show}} {{this.hide}} Spray Foam Insulation Products for Builders

Icynene Classic (LD-C-50) Open Cell Spray Foam Insulation image

Icynene Classic (LD-C-50) Open Cell Spray Foam Insulation

Icynene Classic is a high-performance open-cell spray foam insulation product ideal for use in residential interior applications. Icynene Classic allows occupants to experience superior thermal comfort and improved indoor air quality while helping to reduce the risk of moisture problems.

Performance Benefits
  • Aged thermal resistance: 3.7 per inch
  • Construction types: I - V
  • Core density: 0.5 lb.
  • Air impermeable
  • Superior cold temperature adhesion to multiple substrates
  • <5% water absorption
  • Vapor permeable, supports bi-directional drying of assemblies
  • Soft, flexible composition maintains an air seal even after seasonal expansion/contraction of building assembly
Icynene Classic Max (LD-C-50 v2) Open Cell Spray Foam Insulation image

Icynene Classic Max (LD-C-50 v2) Open Cell Spray Foam Insulation

Icynene Classic Max, together with an unvented attic assembly configuration, can help smother an attic fire in less than a minute! The industry's most thoroughly fire tested spray foam insulation material can help enhance your reputation and the quality of your homes. This low-VOC, ignition barrier-free spray foam also allows for re-occupancy after two hours of active ventilation (at 40 ACH) following installation, meaning less inconvenience for homeowners and a shorter construction schedule.

Performance Benefits
  • Aged thermal resistance: 3.7 per inch
  • Construction types: I V
  • Core density: 0.5 lb.
  • Superior sound control
  • Vapor permeable, supports bi-directional drying of assemblies
  • <5% water absorption
  • Can be sprayed in a wide temperature range for applications, making it suitable for any climate
  • Ignition barrier free-material for residential unvented attic applications
  • Low-VOC, allowing for re-entry in one hour and re-occupancy in two hours at prescribed ventilation rate
Icynene Classic Plus Open Cell Spray Foam Insulation image

Icynene Classic Plus Open Cell Spray Foam Insulation

Icynene Classic Plus is a high R-value open-cell spray foam that achieves R-22 in 2x6 wall assemblies. Suited for use in residential interior applications, the superior performance of Icynene Classic Plus is ideal for builders in areas requiring a higher R-value to meet the latest building codes.

Performance Benefits:
  • Aged thermal resistance: 4 per inch
  • Construction types: V B
  • Core density: 0.7 lb.
  • Air impermeable
  • Superior sound control
  • Class III vapor retarder at 4.25 inches
  • Soft, flexible composition maintains an air seal even after seasonal expansion/contraction of building assembly
Icynene ProSeal (MC-C-200v3) Closed Cell Spray Foam Insulation image

Icynene ProSeal (MC-C-200v3) Closed Cell Spray Foam Insulation

Icynene ProSeal is a high-performance, low-VOC closed-cell spray foam insulation product that sets a new benchmark in excellence. Icynene ProSeal allows you meet today's building code requirements with confidence while meeting tight construction schedules, thanks to its short re-entry time possibilities. Closed-cell spray foam insulation meets the criteria set by FEMA for resisting bulk water, making it ideal for use in zones prone to flooding and hurricanes.

Performance Benefits
  • Aged thermal resistance: 7.1 per inch
  • Construction types: I - V
  • Core density: 2.4 lb.
  • Low VOC
  • Air impermeable
  • One formulation suitable for year-round use
  • Higher initial pass of 3" to achieve R-21 in one pass
  • Class II vapor retarder at 1.5" thickness
  • Meets FEMA criteria for resisting water absorption
  • Compliant to California Department of Public Health EHLB v1.1-2010 Emissions Specification Section 01350
  • Low VOC allowing for re-entry in one hour and re-occupancy in two hours at prescribed ventilation rate
Icynene ProSeal Eco (MD-R-210) Closed Cell Spray Foam Insulation image

Icynene ProSeal Eco (MD-R-210) Closed Cell Spray Foam Insulation

Icynene ProSeal Eco is a 100% water-blown closed-cell spray foam insulation product certified for use in buildings in North America. With no synthetic blowing agent, Icynene ProSeal Eco is an environmentally smart replacement for chemically based medium-density, closed-cell spray foams. As a high-performance insulation, Icynene ProSeal Eco will also smoothly and completely cover all areas that could otherwise allow energy-draining thermal bridges. Closed-cell spray foam insulation meets the criteria set by FEMA for resisting bulk water, making it ideal for use in zones prone to flooding and hurricanes.

Performance Benefits
  • Aged thermal resistance: 4.9 per inch
  • Construction types: I - V
  • Core density: 2.2 lb.
  • Can be sprayed year-round, even at temperatures as low as 5oF
  • Air impermeable
  • 100% water blown
  • Class II vapor retarder at 2.4" thickness
  • Meets FEMA criteria for resisting water absorption
  • Compliant to California Department of Public Health EHLB v1.1-2010 Emissions Specification Section 01350
Icynene MD-C-200 Closed Cell Spray Foam Insulation image

Icynene MD-C-200 Closed Cell Spray Foam Insulation

Icynene MD-C-200 closed-cell spray foam insulation allows builders to push the limits of design while meeting or exceeding local building code requirements. A robust, two-pound closed-cell spray foam insulation, Icynene MD-C-200 is ideal for residential insulation applications and is ABAA approved. Closed-cell spray foam insulation meets the criteria set by FEMA for resisting bulk water, making it ideal for use in zones prone to flooding and hurricanes.

Performance Benefits
  • Aged thermal resistance: 6.6 per inch
  • Construction types: I - V
  • Core Density: 2.2 lb.
  • Evaluated and listed by ABAA as an air barrier material
  • Class II vapor retarder at 1.5" thickness
  • Meets FEMA criteria for resisting water absorption
  • Compliant to California Department of Public Health EHLB v1.1-2010 Emissions Specification Section 0135
Residential / Builders Applications image

Residential / Builders Applications

Whether an unusual design, a new home or part of an existing home renovation, Icynene spray foam insulation can adhere to most substrates, including steel, wood, concrete, and masonry. Icynene spray foam insulation is effective in any climate to benefit homeowners in energy efficiency, noise reduction, moisture control and improved indoor air quality.

In addition to the overall benefits of Icynene, there are more reasons for its use within specific areas of the home. Discover how and where Icynene spray foam can be used below.

Find detail drawings, design notes, 3-part specs, code information, project examples and more below!

Basement
Bonus Room
Cathedral Ceilings
Crawl Spaces
External Wall
Internal Wall
Unvented Attic
Vented Attic
Other Applications
Builders Sustainability image

Builders Sustainability

Green Your Next Building Project with Icynene
  • Better energy efficiency (reduced greenhouse gas emissions)
  • Healthier indoor environments
  • Less excess materials
  • Safer formulas
  • Renewable-based option available


While most traditional insulation types only provide R-Value, building science shows us that an air seal, like that provided by Icynene, is imperative for total building performance. Protecting against air leakage with Icynene means that homeowners can significantly reduce CO2emissions and save up to 50% in energy costs related to heating and cooling. On average, the energy savings can exceed the installation price within three to four years. Plus, an energy saving air seal help keep airborne pollutants, allergens and moisture out ensuring a healthier and cleaner indoor air environment.

Icynene's dual performance function of R-Value plus air sealingalso means that the amount of building materials required is less and can also shorten construction schedules. Icynene works for the life of the building, eliminating the need for replacement or additional materials and waste.

.

{{this.show}} {{this.hide}} Spray Foam Insulation for Home Owners

Choosing the Right Insulation image

Choosing the Right Insulation

Whether you're building a new home or renovating your existing home, the right insulation plays a critical role in providing protection and comfort for you and your family.

Although it's behind the walls, choosing the right insulation can help you save up to 50% in heating and cooling costs.
