Products		Trade Name	Description	Content
	Framing Systems
	CS Clear Span		click to enlarge Tapered columns and rafters give optimum clear span capabilities while keeping unused interior clearances at a minimum.
	MS Multi Span		click to enlarge Offers the most economical cost per square foot for buildings over 80' wide. Ideal design when interior columns are not objectionable.
	CL Classic		click to enlarge Straight columns and rafters. This design is common on smaller width buildings. Easy to finish the interiors.
	HS High Span		click to enlarge Gives the same design benefits as the CS. Steeper pitch offers more interior height when required.
	SST Single Slope		click to enlarge Single slope, tapered columns. Especially suited for commercial stores. Offered with interior columns as well.
	SSS Single Slope		click to enlarge Single slope, straight columns. Best suited for smaller spans where interior floor space is essential. Also commonly used when adding to an existing building.
	LT Lean-To		click to enlarge Used to add space at sides or ends. It differs from the single slope in that it must be supported on the high side by an adjoining building column.
	Custom Designs		click to enlarge Special framing systems can be provided to meet unusual building requirements.
	Roof Panels
	Purlin Bearing Rib		click to enlarge The “PBR” roof covering panel , with 36" wide coverage and 1¼" rib height at 12" on center, is by far the most popular roof choice.
	Ultra-Dek®/Double Lok® Standing Seam		click to enlarge These are virtually leak-free, high performance roofs. Concealed attachment clips essentially eliminate panel penetrations. Ultra-Dek is snap-seamed; Double-Lok* requires a mechanical seamer..
	BattenLok® Roof Standing Seam		The BattenLok is a mechanically seamed roof panel Producing aesthetically pleasing architectural designs, especially hips and valleys. Used frequently for turndown mansards.
	LokSeam® Roof Standing Seam		The LokSeam is a snap together, architectural panel system which can be installed over purlins or solid substrate. Easy to flash and seal.
	Wall Panels
	“PBR” Panel		The most popular wall panel due to its strength, appearance and economic value. This panel provides a full 36" wide coverage. It is cut to length and available in a wide variety of colors.
	“A” Panel		The “A” wall panel features a semi-concealed fastener appearance provided by reverse corrugations.
	ShadowRib™ Panel		The ShadowRib™ wall panel features a totally concealed fastener system which gives an outstanding aesthetic quality. The ribs of the wall panel project to the interior of the structure.
	Soffit and Liner Panels “U” Panel		The “U” soffit and liner panel offers superior strength and coverage. Its ¾" high ribs are located 6" on center across its 36" wide coverage.
	Artisan		The Artisan soffit panel is a concealed fastener soffit panel which offers a smooth, flat appearance.
	Trim
	“J” Trim		Used at jambs of wall openings or doors.
	Corner Trim		Trim used to close the junction of side and endwall sheets. Used at outside of corner of building with wall panels.
	Eave Trim		Trim used to close off top of sidewall panels in lieu of eave gutter.
	Eave Gutter		Used for carrying rainwater off the roof. Placed at low eave of buildings.
	Rake Trim		Used to close off the intersection of roof and endwall panels.
