Protege 5442 - Low-Rise Vertical Platform Lift

Ascension Protege is an ADA-compliant vertical platform lift (VPL) engineered to provide dependable vertical access from 4″ to 42″ in commercial, institutional, and public environments.

Designed to eliminate extended ramp runs and avoid oversized tower systems, Protege delivers high-capacity performance in a compact, pitless configuration. Its clean structural profile minimizes construction impact while maintaining full ADA platform dimensions.

With a 900 lbs. rated capacity, Protege accommodates larger power chairs and mobility scooters without increasing system size or visual disruption.

Protege is specified for schools, performing arts venues, museums, municipal facilities, commercial entries, and stage access applications where elevator infrastructure is unnecessary but architectural integration remains important.

Available in portable and permanent configurations, Protege provides flexible accessibility with simplified installation and long-term reliability.

Key Features & Benefits

• ADA-compliant vertical platform lift (ASME A18.1)

• Vertical travel: 4″–42″

• 900 lbs. rated capacity

• Pitless, ramp-free installation

• Towerless configuration for clean architectural integration

• Compact footprint with full-size ADA platform

• Quiet electro-hydraulic drive system

• Portable and fixed installation options

• Designed and manufactured in the USA


Technical Highlights

• Vertical Travel: 4″–42″

• Capacity: 900 lbs.

• Platform Size: Approx. 36″ W x 54″ L

• Overall Footprint: Approx. 52″ W x 61″ L

• Drive: Electro-hydraulic

• Compliance: ADA, ASME A18.1



Model Configurations

Protege 5442F- Fixed with Upper Platform Gate
Independent upper landing gate configuration to meet specific code or safety requirements.
Protege 5442FG- Fixed with Upper Landing Gate
Independent upper landing gate configuration to meet specific code or safety requirements.
Protege 5442FX- Fixed with Upper Landing Door
Upper landing door for projects requiring a more enclosed or architecturally integrated presentation.

Protege 5442FF- Fixed with Lower Landing Door (Third-Party)
Lower landing door configuration to support custom project requirements.

Protege 5442FE- Fixed with Doors at Both Landings
Shaftway-style installation with doors at both levels, delivering a more elevator-like presentation while maintaining platform lift efficiency.
